Harley tranny crack/weld, rebuild, project #2

Printable View

10-12-2011, 04:00 AM
hooda

Harley tranny crack/weld, rebuild, project #2

Hooda's Project #2

So, this started out as a run of the mill build on a '76 vintage Harley 4 speed tranny. That was until I forgot the assembly sequence, one that I had done dozens of times over the years, but not for the last 6 years or so. In my infinite wisdom, I got it stuck in my head that an extra washer just HAD to fit into the countershaft assembly, in spite of the fact that it was proving to be a mechanical impossibility. Rather than wait and go toone of the shops I go to for parts and ask, I decided that the case must have gotten "bent", so I set up some wood blocks, got out the 5 pound lead hammer, and proceeded to "straighten it". The case survived 5 solid blows until it not only didn't straighten, but instead cracked neatly down the side.

http://i985.photobucket.com/albums/a...d/DSCF1841.jpg

The crack starts on top to the left of the small hole, and snakes it's way down and to the right. Here's a top view

http://i985.photobucket.com/albums/a...d/DSCF1840.jpg

And an inside view

http://i985.photobucket.com/albums/a...d/DSCF1835.jpg

Next post will show the welds, but it's lites out for now..
10-12-2011, 10:25 AM
hooda

the cause

As mentioned above, I was trying to fit a countershaft assembly shown here

http://i985.photobucket.com/albums/a...2/DSCF1907.jpg

into the case. Here, I'm measuring the length of the assembly. Tha mistake came by the face that there's loose needle bearings in either end, with counterbores of differing depths, and 3 different thrust washers that go into the ends. 2 of the same in one end, one of those and one of varying thicknesses on the other end. I was going under the assumption thet a fourth washer of the first type went on before the variable thickness washer, and trying to "adjust the case accordingly", even with a factory service manual vaguely telling me different. My mistake, which I didn't figure out til the damage was done. I guess that I post these type of mistakes (on an HD forum, too), hoping to educate my peers, rather than have them do the same.
Here's where the variable thickness washer rides. Reason for the variable thickness is to set endplay. The basic design of this tranny dates back to 1936, essentially UNCHANGED until 1978-1/2, when the switch from loose needle bearings to inferior torrington-style bearings was made.

http://i985.photobucket.com/albums/a...2/DSCF1905.jpg

Below is a pic of the washer in question.

http://i985.photobucket.com/albums/a...2/DSCF1911.jpg
10-12-2011, 11:51 AM
DaveO

I have the OEM shop manual for my car and have been staring at it for 15 years- it's very badly written, so I know what you mean about vague manuals. I notice the crack runs through a threaded bolt hole- do you run the danger of weld heat warping the metal slightly, and skewing those threads or any gasket mating surfaces?
10-12-2011, 12:49 PM
hooda

The weld/repair

Here's some pics of the actual weld, and the finish work I had to do to get this thing ready for assembly.

http://i985.photobucket.com/albums/a...1/DSCF1845.jpg

http://i985.photobucket.com/albums/a...1/DSCF1846.jpg

http://i985.photobucket.com/albums/a...d/DSCF1890.jpg

Out of time. I will post pics of the completed tranny as soon as I can find them!

http://i985.photobucket.com/albums/a...d/DSCF1892.jpg

http://i985.photobucket.com/albums/a...d/DSCF1893.jpg

http://i985.photobucket.com/albums/a...2/DSCF1913.jpg
10-12-2011, 12:57 PM
hooda

Quote:

Originally Posted by DaveO

I have the OEM shop manual for my car and have been staring at it for 15 years- it's very badly written, so I know what you mean about vague manuals. I notice the crack runs through a threaded bolt hole- do you run the danger of weld heat warping the metal slightly, and skewing those threads or any gasket mating surfaces?

http://i985.photobucket.com/albums/a...d/DSCF1895.jpg

Funny you should ask. I had to re-drill and tap 2 holes. Fortunately, they were non-critical, both in location, and function. LOTS of hand-filing to work around press-fit studs and screw-ins that may as well have been press fit. Due to the wide-open nature of this tranny, I was able to successfully get everything straight/true/flat enough for it to go back together with no issues whatsoever. Had this been a more modern 5, 6, or 7 speed (yes, there is actually a freaking 7 speed available nowadays!) I have doubts as to whether this type of repair would have been possible to do this way. Possible yes, but it would have required much more precision, more disassembly, and a bridgeport mill to get things beck in line.
10-12-2011, 02:21 PM
67cudafb

Memory is the first thing to go, mine left and I am still looking for it. What was I saying? Looks like a whole lot of work to repair, nice job though. My concern would be that looks like high stress area with the gears pushing against each other. I would not dump clutch it could be ugly.
10-12-2011, 04:43 PM
Trip59

Did you do anything special to prep before welding? I've got my 59 ironhead sitting in crates till I get geared up to repair the cases (also waiting till I have a mill in the shop...) but old, grease soaked castings give me a bit of pause.
10-12-2011, 11:55 PM
sportbike

Did you just throw a weld on the surface of the case? If so, I'm not so sure that is going to survive the vibration of a Shovelhead :-)
10-13-2011, 12:38 AM
jerky

man that was one nasty crack. like sportbike said, i hope it holds up. how much more time did you spend fixing the "bent" casae?
10-13-2011, 03:40 AM
hooda

Quote:

Originally Posted by Trip59

Did you do anything special to prep before welding? I've got my 59 ironhead sitting in crates till I get geared up to repair the cases (also waiting till I have a mill in the shop...) but old, grease soaked castings give me a bit of pause.

I was fortunate enough to have this happen while the cases were clean enough to eat off of, when I reassemble a rebuilt part, it's surgically clean, but to be safe, I cleaned everything with chlorinated brake cleaner, followed by acetone, followed by hot, soapy, then hot clear water. (remember the phosgene warning). I was limited by accesibility to form any deep vee's or anything, so I made sure to have enough amps to get good penetration.
10-13-2011, 03:45 AM
hooda

Quote:

Originally Posted by jerky

man that was one nasty crack. like sportbike said, i hope it holds up. how much more time did you spend fixing the "bent" casae?

My STUPIDITY, all said and told, cost me a total of about 7-8 hours, if you count the time spent inventing new swear-words to express my frustration with:D
10-13-2011, 04:01 AM
DVA

Quote:

Originally Posted by hooda

I was fortunate enough to have this happen while the cases were clean enough to eat off of, when I reassemble a rebuilt part, it's surgically clean, but to be safe, I cleaned everything with chlorinated brake cleaner, followed by acetone, followed by hot, soapy, then hot clear water. (remember the phosgene warning). I was limited by accesibility to form any deep vee's or anything, so I made sure to have enough amps to get good penetration.

Deep penetration may not be enough if the crack was not ground out. If your weld is fused with the crack you have a crack already started. Crack tips have almost infinite stress concentrations as this is what helps cracks grow. The stored energy at the tip of a crack is released by the elongation of the crack when stresses are high enough to overcome the material properties. This is why drilling a hole at a crack tip helps stop the crack propagation because it allows the stresses to distribute more evenly and not allow the material to reach the point to allow a crack to grow further. I would keep a close eye on the repair. Would hate for you to be on a long drive and end up with no oil in your gear box.
10-14-2011, 12:34 AM
SeanMurphy265

Do you need to bake/pre-heat something like that before you weld?
10-14-2011, 03:12 AM
DVA

Quote:

Originally Posted by SeanMurphy265

Do you need to bake/pre-heat something like that before you weld?

Pre-heating will help relieve stresses in the weld and provide a better product. With some code welds base metal repairs deeper than an 1/8 of an inch require pre-heating due to residual stresses in the weld when it cools.
10-14-2011, 04:05 AM
Trip59

Quote:

Originally Posted by hooda

I was fortunate enough to have this happen while the cases were clean enough to eat off of, when I reassemble a rebuilt part, it's surgically clean, but to be safe, I cleaned everything with chlorinated brake cleaner, followed by acetone, followed by hot, soapy, then hot clear water. (remember the phosgene warning). I was limited by accesibility to form any deep vee's or anything, so I made sure to have enough amps to get good penetration.

I've been thinking about cooking some parts in a crockpot in a degreaser, though I haven't found a good one to use (no, I'm not cooking alcohol, don't care what the old timers did)

One of the things that scares me about repairing my cases are all the cracks and the roots. Going to wind up with a ton of weld, I'm worried about warpage control.
10-14-2011, 04:52 AM
hooda

Quote:

Originally Posted by Trip59

I've been thinking about cooking some parts in a crockpot in a degreaser, though I haven't found a good one to use (no, I'm not cooking alcohol, don't care what the old timers did)

One of the things that scares me about repairing my cases are all the cracks and the roots. Going to wind up with a ton of weld, I'm worried about warpage control.

In the case of old HD repair, It's best to take the expert advice such as some that's been given in this thread and toss it out the window. With these dinosaur-ish castings, you have to acquire a "feel" for whether your repair is going to be good, or not. There's basically someone here telling me blah blah this and that, but I've made several of these type of repairs, all without the dreaded stress cracks, all without pre-heating, and so far, all still oil-tight and running fine. I got US $20.00 that says that this case is still intact and oil tight 5 years from now, and on a running, 85 horsepower/85 ft.lb. bike. That's how confident I am of the repair. If you need help coming up with a strategy to weld up your sportster cases, keep in mind that they are a completely different animal, and I'm willing to give you assistance in setting up a plan for cleaning, pre-heat, and the proper welding of your cases. Just let me know
10-14-2011, 05:37 AM
Trip59

Appreciate it! It'll be a while before I think about it, lots of other projects, need to acquire a mill, need to put at least 100 hours through the TIG machine I haven't even gotten yet before I'd think about taking torch to a set of 59 cases...

Of course, time comes, I might take them to a local shop and just have them vatted...

Just an idea of the extensive repairs, the ear for the gennie snapped a while back (before I had it) and was welded back together not quite right, the bushing for the idler wasn't machined right and it came loose and wore out the boss. The left side, 3/4 of the primary bolt holes are cracked on the inside and need to be welded, re-drilled and tapped. There are a few stress cracks in the web and one ear of the tranny door is broken. That's what I can recall, it's been two years since I crated it for long term storage.

Folks say scrap em and buy aftermarket or ebay, but hell, they're 1959 sporty cases, they're the soul of the bike http://lh6.googleusercontent.com/-1C...1%252520PM.jpg
10-14-2011, 02:39 PM
hooda

Quote:

Originally Posted by Trip59

Appreciate it!
Of course, time comes, I might take them to a local shop and just have them vatted...

Folks say scrap em and buy aftermarket or ebay, but hell, they're 1959 sporty cases, they're the soul of the bike http://lh6.googleusercontent.com/-1C...1%252520PM.jpg

GREAT PHOTO!! You are correct about the cases being the soul of the bike, especially if your state is like MN where the title on pre-1970 bikes attaches to the ENGINE serial number, not the frame. I've seen cases that have literally feet of weld, and were at one time broken into 5 or more pieces that have been beautifully repaired, done by crusty, old school guys using crusty, old school equipment. A lot of whether a repair of this nature is success or failure has to do with the time the person doing it is willing to spend, and the PATIENCE necessary to get it right. The repair I did on this tranny was in an area that LOOKS like a high stress area, but it's not as bad as it looks. Now, I can't wait to get into a new, modern EVERLAST machine, as I strongly believe that if I can do these repairs with the dinosaur equipment I've been stuck using so far, having the capabilities to adjust balance, frequency, and actually having a pulse feature will enable me to do things not previously possible (for me at least). Can't wait!!
